Intelligent Electronic Spot Welding Machine - Available Models

SMAPRO 100S (Energy Storage Type)The SMAPRO 100 electronic spot welder is suitable for welding enameled wire or metal wire with a diameter of Φ0.02-0.30mm. It employs an advanced pressure sensor and electronic control system to precisely control the output voltage, time, and welding pressure. A built-in current sensor monitors the quality of each weld point. It features stable output, precise control of welding energy, small weld points, good conductivity, low signal attenuation, accurate welding head positioning, and long service life. It can directly weld enameled wire, all-metal wire, metal strips, metal sheets, solar cells, etc. It is widely used for contact welding of various micro-components and is currently widely used by manufacturers of surface mount inductors, surface mount transformers, micro-sounders, high-frequency communication components, inductive IC cards, watch coils, modules, etc.Detailed IntroductionJIYI Electronic Spot Welding Machine Performance Indicators1 - Power input: 220V, 50HZ, 280VA (220V±5V) 115V, 60HZ, 280VA (115V±5V)2 - Maximum output pulse power: 540VA3 - Welding frequency: 120 times / minute4 - Welding pulse width: 0.1~29.9ms (subdivision accuracy 0.1ms)5 - Main pulse amplitude: 0.01~1.99V (subdivision accuracy 0.01V)6 - Welding pressure: 30-3000g or 50-4500g (10g fineness)7 - Welding wire diameter: Ф 0.02 mm — Ф 0.30 mm8 - External dimensions: Main unit 330 x 195 x 160 mm9 - Foot pedal cable length: 2.3 meters10 - Workbench dimensions: 400mm (width) x 600mm (length) x 12mm (thickness)11 - Total weight: 28 kgConfiguration Features1 - Main unit configuration: Configuration of main unit, board frame, pedal, CCD and LCD display.2 - Precision welding: Suitable for precision welding, it is less likely to cause visual fatigue to workers and is easy to operate.3 - Automated production lines: Suitable for use in automated production lines, it does not require the installation of tables or drilling, and can be used directly on the production line.This product was entirely developed independently by our company and has a English invention patent (see homepage for details). You are welcome to visit our company to learn more or call us for inquiries.

Model: SMAPRO 180B (Energy Storage Type)This electronic spot welding machine adopts advanced microcomputer control technology and has the function of interfacing with an automatic platform. All parameters of this electronic spot welding machine can be automatically adjusted or set by the automatic platform or robot. During automatic welding, the PLC of the automatic platform can adjust the welding parameters in real time. Especially for the automatic welding of different weld points and different strands of enameled wire, it realizes the function of automatically adjusting welding parameters. The main unit stores 20 sets of welding parameters for convenient user access and reference.Detailed IntroductionFeatures1 - This intelligent electronic spot welding machine adopts advanced microcomputer control technology and has the function of real-time docking with robotic arms or PLCs. It is the first choice for automatic electronic spot welding machines and can realize automatic positioning and welding of spot welding machines. There are 20 sets of welding parameters inside for users to select.2 - It has RS485 and RS232 interfaces, which can be connected to a computer. Through the monitoring software developed by our company, welding parameters such as voltage, current, welding pressure and weld point can be monitored in real time, and the welding voltage and current waveforms can be displayed on the computer in real time.3 - The most prominent advantage of this equipment is that it breaks through the traditional production process and technology, directly removing the enamel from the enameled wire and simultaneously welding it to the workpiece, resulting in a clean and tidy product free from pollution and corrosion. This equipment is mainly suitable for robotic arms, automatic platforms, vision positioning systems, and a wide range of manual welding users.4 - The monitoring software has a database that can track and store all welding parameters within one month, facilitating users' production and management.5 - The unique internal current tracking function enables constant current welding, ensuring the welding quality of the product.6 - This product features fully digital control, unique button management, a large 160*160 English LCD screen, a user-friendly display interface, and easy operation.7 - The internal storage contains 20 sets of welding specifications for easy access and storage by users.Main Technical Specifications1 - Power input: 220V, 50HZ, 280VA (220V±5V) 115V, 60HZ, 280VA (115V±5V)2 - Maximum output pulse power: 800VA3 - Welding frequency: 120 times / minute4 - Welding pulse width: 0.1~29.9ms (subdivision accuracy 0.1ms)5 - Main pulse amplitude: 0.01~1.99V (subdivision accuracy 0.01V)6 - Welding pressure: 30-3000g or 50-4500g (with a fineness of 10g)7 - Welding wire diameter: Ф0.02 mm—Ф0.40 mm8 - Dimensions: Main unit 360 x 180 x 185mm9 - Weight: 27kgThis product was entirely developed independently by our company and has a English invention patent (see homepage for details). Please feel free to contact us for inquiries.
